Urban cycling
Lightweight jackets for daily rides and active commuting.
WS1Q1006
Ultralight performance
A 6 g/m² nanofiber membrane for lightweight garment development, from cycling and golf jackets to down outerwear and stretch shells.
Membrane basis weight
6 g/m²Membrane performance
Product brochure (English) ↗Values are reproduced from the product brochure and refer to the listed membrane grades. Test methods are shown separately; results across methods are not directly interchangeable. Finished laminate performance depends on fabrics, adhesive, processing and care. Confirm the current specification and test report for your project.
| Property / test method | WS1Q1006 |
|---|---|
| Basis weightg/m²Nominal value | 6 |
| Hydrostatic pressure · GB/T 4744-2013mmH₂O | 1,000 |
| Hydrostatic pressure · JIS L1092-2025 BmmH₂O | 6,000 |
| Air permeability · GB/T 5453-1997mm/s | >10 |
| Elongation · GB/T 3923.2-2013% | >100 |
| Thickness · GB/T 3820-1997µm | 10 |
| Moisture vapor transmission · JIS L1099-2021 B1g/m²/24h | >28,000 |
Finished fabric possibilities
Lightweight apparel
Lightweight fabric development with a 6 g/m² nanofiber membrane, for cycling, down outerwear, golf jackets and stretch shells.
DEVELOPMENT TARGETS · BEFORE WASHING
- Waterproofness
- ~9,000mmH₂O
Target evaluation methodJIS L 1092:2025 B
- Water-vapour transmission
- ~28,000g/m²/24h
Target evaluation methodJIS L 1099:2021 B-1
- Air permeability
- ~10mm/s
Target evaluation methodGB/T 5453-1997
Indicative development targets before washing, not measured results. Final laminate performance is validated with the selected fabrics, lamination process and test method.
Request a sampleMore ways to use it
Application examples are development directions. Validate the complete laminate against the requirements of your intended use.
